Achieve Energy Independence Today with the Titan 48™ Power System

GPTS TITAN 48™ LUXPOWER | Priority Off-Grid Solar System 12kW + 48.23kWh of Storage + (36) SUNPLUS 445W Bifacial Panels

WHAT'S INCLUDED

• 1 LUXPOWER SNA-US 12K Split-Phase 120/240V Inverter

• 3 PSHIELD MAX 51.2V 314Ah LiFePO₄ Batteries (16.076kWh each)

• 36 SUNPLUS SR4-54HTB-445M Bifacial N-Type 445W Solar Panels

• 48.23kWh of total storage

• 16.02kW of installed solar generation

• Intelligent system monitoring

• 5-Year GPTS Elite Protection Plan

PURPOSE

This solar system was designed to operate primarily off the power grid. During the day, solar energy powers the business or residence loads and simultaneously recharges the batteries. During the night, the batteries supply the stored energy, leaving LUMA as occasional backup.

IDEAL FOR

• High-consumption residences

• Offices

• Medium-sized restaurants

• Businesses

• Clinics and medical offices

• Workshops and small warehouses

OPERATING SCENARIOS

Approximate electric bill: $600/month

• Expected coverage: up to 100%

• Virtually permanent Off-Grid operation

• Estimated residual bill: $0 to $30

Approximate electric bill: $800/month

• Expected coverage: 95% to 100%

• Mostly Off-Grid operation

• Estimated residual bill: $0 to $40

Approximate electric bill: $1,000/month

• Expected coverage: 90% to 95%

• Solar energy as the main source

• Estimated residual bill: $50 to $100

ESTIMATED SAVINGS IN INTERCONNECTED SELF-CONSUMPTION

Current bill: $600

• Estimated savings: $540 to $600

• Residual bill: $60 to $0

Current bill: $800

• Estimated savings: $720 to $800

• Residual bill: $80 to $0

Current bill: $1,000

• Estimated savings: $900 to $950

• Residual bill: $100 to $50

TECHNICAL SPECIFICATIONS

LUXPOWER SNA-US 12K Inverter

• 12,000W continuous

• 120/240V Split-Phase

• Up to 24,000W in solar panels

• Integrated AFCI protection

• 5-year factory warranty

PSHIELD MAX Batteries

• LiFePO₄ technology

• 16.076kWh per battery

• 48.23kWh total

• 51.2V nominal

• IP65 protection

• More than 8,000 cycles at 80% DoD

• More than 20 years of useful life under one daily cycle

• 10-year factory warranty

Solar Panels

• 36 bifacial N-Type panels

• 445W per panel

• 16.02kW DC installed

FUTURE EXPANSION

• The inverter supports up to 24kW of photovoltaic generation.

• The system can be expanded up to 4 PSHIELD MAX batteries in this inverter configuration.

• It can grow by adding additional inverters in parallel.

• PSHIELD MAX batteries allow scalable architectures of up to 35 units in properly designed configurations.

WARRANTIES AND PROTECTION

• LUXPOWER inverter: 5-year factory warranty.

• PSHIELD MAX batteries: 10-year factory warranty.

• 5-Year GPTS Elite Protection Plan included.

Protection in the United States and Puerto Rico against accidents, repairs, or replacement, with no deductibles. Superior to any factory warranty.

At Green Power Tech Store we protect your investment.

📋 Registration required once your equipment arrives As soon as your equipment arrives, register it at greenpowertech.store/registro-garantia. Once your registration is complete, we'll process your 5-Year Protection Plan and register your equipment with the manufacturer for its warranty -- you'll receive your Registration Certificate by email once everything is finalized.
